Emerson White-Rodgers All-Spark Ignition Module Installation

Dirk is replacing a Honeywell intermittent-pilot igniter with a round spark connector, also called a rajah. To configure the All-Spark to the original igniter’s settings, Dirk uses the Emerson White-Rodgers Connect App. Then, he simply installs the All-Spark wire by wire.

After installing the All-Spark, you simply have to start up the furnace and test it. You can then use the White-Rodgers Connect App to help with troubleshooting and diagnostics, or you could simply use it to keep an eye on the system’s status.

You can learn more about the All-Spark at https://hvacrschool.com/allspark.
