Suppose you have two extension cords. One is a nice, thick #10 50′ cord with good ends, and the other is a crappy #14 25′ cord. Unfortunately, you need to connect them both to get to your drill 75′ away. Which do you connect to the plug, and which to the drill? Come up with […]

Parallel Circuit Resistance

In a series circuit (loads connected in a row end to end), it's easy to calculate total circuit resistance because you simply add up all the resistances to get the total. In a parallel circuit, the voltage is the same across all the loads; the amperage is simply added up, but the resistance is a […]

What Causes Voltage Drop and How to Deal With It

Voltage drop is one of those topics we often mention but seldom think about in-depth. From a very basic standpoint, we need to know whether or not the rated voltage is being delivered to the device or appliance while under full load, which is as simple as running the equipment and measuring the voltage at […]

Check out our most recent video

How to Evacuate an AC system, Full Vacuum Procedure

Our latest Podcast

HVAC School – For Techs, By Techs

Real training for HVAC ( Heating, Ventilation, Air Conditioning and Refrigeration) Technicians. Including recorded tech training, interviews, diagnostics and general conversations about the trade.

Bryan discusses surge protection devices (SPDs) with Mike from DITEK, focusing on practical applications for HVAC contractors and how to provide value to clients. Mike emphasizes that surge protection is essential for modern HVAC systems, particularly given that they are typically the most expensive appliance in a home and increasingly rely on sophisticated electronic components like variable-speed compressors and inverter boards.

The conversation delves into installation best practices, with a detailed discussion of proper wiring techniques for SPDs. Mike explains that surge protectors should be installed in parallel with the circuit, typically at the disconnect, and addresses common concerns about double-tapping lugs and ground connections. He emphasizes the importance of keeping wire lengths as short as possible and provides guidance for installations both with dedicated disconnects and panel-direct connections.

A significant portion of the episode focuses on DITEK’s Kool Guard (KG2) product, which represents an evolution in HVAC protection by combining surge protection with voltage monitoring. Mike explains how modern HVAC equipment, particularly inverter-driven systems, is increasingly sensitive to both over-voltage and under-voltage conditions. The Kool Guard monitors voltage on each phase independently and provides visual indication of fault conditions through LED indicators, making it easier for homeowners to identify potential issues without opening electrical enclosures.
