Teaching the Invisible with Ty Branaman

September 22, 2024

Join us for an engaging and insightful presentation by Ty Branaman on "Teaching the Invisible" from the 5th Annual HVAC/R Training Symposium. In this video, Ty demonstrates innovative ways to make abstract HVAC concepts tangible and exciting for learners.

Highlights include:

Visualizing air movement and pressure differentials
Understanding heat transfer and evaporation
Demonstrating refrigeration principles with everyday objects
Creative approaches to explaining combustion and gas laws

#education #hvac #HVAC education #HVACR #teaching #training
