The “Other” Pressure Switch

The chart above is from a Carrier heat pump, and it lists some common accessories.

I have heard this common pressure switch (last on the list) called a low-pressure switch (because it opens on fall in pressure) and a high-pressure switch (because it's in the liquid line), but RARELY do I hear it called its true name.

Loss of charge switch

In a heat pump system, the operational suction pressure can vary greatly from the suction you will run on a hot day in cool mode to the suction you will run on a cold winter day in heat mode. That makes a traditional low-pressure switch a challenge.

The loss of charge switch performs much the same role as the low-pressure switch, but since it is in the liquid line in cool mode (before the metering device and after the condenser) and the expansion line in heat mode (after the metering device and before the outdoor coil), it will not be as prone to fluctuations. It will only keep the system off in cases of very low charge or “loss of charge” in cool mode.

In heat mode, it will open during a loss of charge but also if there is a line drier or heat mode metering device restriction.

All in all, it's pretty easy to understand, so long as you know its true identity and purpose.

—Bryan

Related Tech Tips

Drain Cleaning Protocol
This article is primarily based on HVAC School’s “Drain Cleaning – More To It Than We Think,” hosted by Bryan Orr and featuring Corey Cruz and Mike Klokus. You can listen to that episode HERE. How hard could it be to clean a drain? The slime should just wash away if you flush the drain […]
Read more
The "5 Pillars" of Residential A/C Refrigerant Circuit Diagnosis
Suction pressure, head pressure, subcooling, superheat, delta T. Taking all five of these calculations into account on every service call is critical. Even if you must do further diagnostic tests to pinpoint the problem, these five factors are the groundwork before more effective diagnostics can be done. I would also add static pressure as an […]
Read more
Splicing Wires - Bad, Good, Better, Best
There are many acceptable methods for making a wire splice, and you need to consider many different factors when making a splice. Here are a few considerations. High Voltage vs. Low Voltage – If the connection is 24V or less, it USUALLY has fewer NEC (National Electrical Code) rules and regulations concerning how the connections are […]
Read more

One response to “The “Other” Pressure Switch”

  1. Does this Switch-Loss of Charge works through temperature? I mean, does it detects the loss of charge by sensing the temperature in the liquid line. We have seen it in MrCool ACs (Lennox) cooling only units, just besides the HPS.
