The Universal Integrated Furnace Board with WR Connect from Copeland

August 28, 2024

In this video, Bryan Orr introduces the game-changing 50M56X-843 universal integrated circuit board from White-Rodgers and Copeland. Learn how this versatile replacement part works with both PSC and ECM X (X13) motors, and comes complete with a hot surface igniter.

Key features:

Compatible with most PSC and ECM X motor furnaces
Built-in flame rod current measurement
No additional harnesses or wires needed
Easy configuration using the White-Rodgers Connect app and NFC technology

Watch as Bryan demonstrates the simple setup process using the WR Connect app, showcasing how you can quickly configure the board to match OEM specifications or make custom adjustments. Whether you’re a seasoned HVAC pro or just starting out, this video will show you why the 50M56X-843 is a must-have for your toolkit.

Learn more at https://hvacrschool.com/wrhsi.

#50m56x-843 #copeland #furnace #hvac #ifc #integrated furnace board #white-rodgers #wr connect
