Rack Refrigeration Cycle Part 2 – Compression w/ Matthew Taylor

September 29, 2024

Join Matthew Taylor in this informative presentation on the rack refrigeration cycle. In Part 2 of our series, Matthew dives deep into compression and oil management systems in supermarket refrigeration.

Key topics covered:

Types of compressors used in supermarket refrigeration
Oil management systems and their importance
Mechanical and electronic oil controls
Safety switches and their functions
High pressure, low pressure, and oil safety controls
Proper adjustment and testing of safety switches
Overload protection and control circuitry

#commercial refrigeration #compression #compressor #market refrigeration #refrigeration
