Checking the Charge on a Heat Pump in the Winter

When you ask many people nowadays how to check the charge on a heat pump during low outdoor temps, they will say that you need to “weigh in and weigh out” the charge. While this may be an effective method, it isn't always practical.

Now, if you are making a refrigerant circuit repair, weighing out and weighing in makes perfect sense, especially since microchannel condensers and scroll compressors make pumping down less viable anyway. But there are many cases where you just need to check the charge to make sure the system is working properly, and in these cases, weighing in and out would be plain silly.

I originally wrote this guideline back in 2003, and truthfully, not much has changed since then in regards to checking a heat mode charge on a heat pump.

Step #1 – If there is any frost on the outside unit, get it completely defrosted first.

Step #2 – Check all the obvious things first, filter, coils, blower wheel, etc. If the unit isn't clean, it will be really hard to check.

When charging in heat mode, read manufacturer specifications first. Lennox gives specific instructions for charging their units when the outdoor ambient conditions are below 65°. It involves blocking off the condenser coil with cardboard (or, even better, using a charging jacket) while running the system in cool mode. Lennox gives specific instructions for how high to raise the head pressure and what level of subcooling you should expect.

Remember that in heat mode on a heat pump, the evaporator is outside, and the condenser is inside. This is important because, in cool mode, a dirty air filter caused low airflow on the evaporator. In those cases, you would typically notice a low suction pressure and a low superheat. In heat mode, a dirty air filter causes low airflow across the condenser. That can cause extremely high head pressure. In heat mode, a dirty outdoor coil can cause a low suction pressure.

As an example, Trane includes a pressure curve chart with many heat pump condensing units. Be sure to use the scale all the way to the right that says heat mode. Indoor and outdoor dry-bulb temperatures are necessary to use the Trane pressure curve. Carrier supplies many heat pump condensing units with a pressure guideline chart. Carrier only wants the heat mode pressure chart used as a guideline, not as a charging tool. Always reference manufacturer guidelines before setting any charge.

100° Over Ambient Rule of Thumb

Even though we should follow manufacturer specifications, some basic guidelines will aid in charging and diagnosis in a pinch. The most widely quoted rule of thumb is the 100°-110° over ambient discharge rule. This guideline states that a properly charged unit will have a discharge line temperature of 100°-110° above the outdoor temperature. If the discharge line is too hot, add refrigerant (if the charge is the issue and not another problem). If the discharge line is too cool, remove refrigerant (again, only if the charge is diagnosed as the issue).

Keep in mind that this rule only works if you are close to being in the correct zone. For example, an extremely overcharged system with an outdoor TXV can actually show a high discharge temperature. It's just a rule of thumb, and you shouldn't rely too heavily on it.

First off, the photo above was taken in 2003, so give me some slack on my gauges. Nowadays, I would be using my Testo 550s.

To give a simple example using the 100°-110° over ambient rule, if it were 60° outside, you could say that the charge is about correct by the 100°-110° over ambient rule. If it were 30° outside, the 100°-110° over ambient rule would show undercharge (or other conditions that can cause high discharge line temp; see this article). If, for example, the discharge temperature were 210° with a 150 PSI head pressure and a 10 PSI suction with a 50° outdoor temperature, this would show an extreme undercharge. You can still check the subcool and superheat in heat mode; the problem is that since there are rarely any set guidelines, it is difficult to tell when the charge is set correctly by simply checking the subcool or superheat alone. Generally, you will see normal superheat (8°-14°) on a system with heat mode TXV, and the subcooling will generally be a bit higher than usual, especially when measured outside.

Suction Pressure/EVAP DTD Rule of Thumb

Another common old-school rule of thumb is that suction pressure should be close to the outdoor temperature in an R22 system. However, this rule of thumb (obviously) does not work on an R-410A system. A more applicable guideline is 20°-25° suction saturation below outdoor ambient. That means if it is 50° outside, the suction saturation temperature should be between 25° and 30° (on most systems).

Head Pressure/CTOA Rule of Thumb

Because the evaporator coil is substantially smaller than the condenser, you will usually see higher head pressure (condensing temperature) in relationship to the condensing air (in this case, the indoor air). This can vary a lot depending on the age/SEER of the unit, the size of the coil, and how the indoor airflow is set up, but generally, it will be 30°-40° condensing temperature over the indoor dry bulb.

Checking Without Gauges

Here are some quick tests you can do on a heat pump to confirm it is operating close to specs without using gauges when the coil is frost-free, and the outdoor temps are 65°-15°:

  • Check the discharge (vapor) line; it should be 100°- 110° over the outdoor ambient temperature.
  • Suction line temp should be 5°-15° cooler than the outdoor temperature.
  • The liquid line should be 3°-15° warmer than the indoor temperature.
  • Delta T indoors will vary greatly depending on the outdoor temperature.

If anything looks off, go ahead and connect gauges to verify further—and as I said several times already, follow manufacturers' guidelines.

The best way is to verify total system capacity (with heat strips off) using dual in-duct thermometers and manufacturer specs, but I understand how challenging it can be to verify system airflow ACCURATELY, so it likely won't always be your first move. We are a big fan of MeasureQuick around our business, so I would suggest checking it out for this.

Here's how we check the charge without gauges at Kalos.

—Bryan

P.S. – I also released two podcast episodes about checking the charge without gauges with Jim Bergmann. You can find those HERE.

Comments

John Lakey
John Lakey @bryanorr

Wow and I hear commercial folks saying residential is easy. Thanks for the info. Of course in Detroit we don’t get many heat pumps. Lol

12/2/17 at 08:53 AM

Wow and I hear commercial folks saying residential is easy. Thanks for the info. Of course in Detroit we don’t get many heat pumps. Lol

    Thomas werts
    Thomas werts @bryanorr

    funny i’ve not seen a residential boiler or a humidifier, 90% furnace since i left Detroit back in 05. we have maybe 2 months of heating, maybe and 10 months of AC. 8 of which are very heavy . so if work ever drys up up there…. move south. oh and be sure to bring me a coney
    Thomas Werts
    New Orleans LA

    1/17/18 at 12:21 PM

    funny i’ve not seen a residential boiler or a humidifier, 90% furnace since i left Detroit back in 05. we have maybe 2 months of heating, maybe and 10 months of AC. 8 of which are very heavy . so if work ever drys up up there…. move south. oh and be sure to bring me a coney
    Thomas Werts
    New Orleans LA

Marc Bilbrey
Marc Bilbrey @bryanorr

I typically charge a heat pump using the total discharge superheat method showed to me by a old school tech which means discharge line temp is 35 to 50 degrees higher than pressure relation temp. Its easier to check on split system. This tells me the unit is picking up good superheat. Less than 35 remove Freon and more than 50 add Freon and works on r22 and 410a.

12/2/17 at 11:18 PM

I typically charge a heat pump using the total discharge superheat method showed to me by a old school tech which means discharge line temp is 35 to 50 degrees higher than pressure relation temp. Its easier to check on split system. This tells me the unit is picking up good superheat. Less than 35 remove Freon and more than 50 add Freon and works on r22 and 410a.

Tom
Tom @bryanorr

Carrier uses a piston in the small line at the outdoor unit.
Connecting to the unit, true suction and large line is used for pressures, but what about temps? You would need to get into the outdoor unit, correct?

12/2/17 at 11:33 PM

Carrier uses a piston in the small line at the outdoor unit.
Connecting to the unit, true suction and large line is used for pressures, but what about temps? You would need to get into the outdoor unit, correct?

Asswipee moronn
Asswipee moronn @bryanorr

I agree with your list. Keep up the good work. But it always better the charge in the cooling mode. For heat pump. Winter charging. Block the condenser. Raise the head pressure to 180psig. And clear the the sight glass. If no night glass . 2-3 degree of sub cool is good. That with all the obvious. Coil, filter and fans are good. Just my opinion. Have fun.

12/17/17 at 09:57 AM

I agree with your list. Keep up the good work. But it always better the charge in the cooling mode. For heat pump. Winter charging. Block the condenser. Raise the head pressure to 180psig. And clear the the sight glass. If no night glass . 2-3 degree of sub cool is good. That with all the obvious. Coil, filter and fans are good. Just my opinion. Have fun.

Joe
Joe @bryanorr

Very educational info for young HVAC technicians. In heat mode, the 100-110 deg above outdoor temp on line temp rule is referring to the temperature on the “big” line (i.e., the suction line in cool mode) at the outdoor unit. What the temp should be on the big line at the indoor unit in heat mode? I have R22 in most units, and have 2 units on R407C. They are York heat pump units. Thanks

6/4/23 at 02:16 AM

Very educational info for young HVAC technicians. In heat mode, the 100-110 deg above outdoor temp on line temp rule is referring to the temperature on the “big” line (i.e., the suction line in cool mode) at the outdoor unit. What the temp should be on the big line at the indoor unit in heat mode? I have R22 in most units, and have 2 units on R407C. They are York heat pump units. Thanks

    Matt Bruner @mattkalosflorida-com

    The temperatures should be roughly the same, although the “vapor”/ big line will be cooler at the indoor unit due to length of lineset and insulation.

    6/14/23 at 04:47 PM

    The temperatures should be roughly the same, although the “vapor”/ big line will be cooler at the indoor unit due to length of lineset and insulation.
