Why is 240V called “Single-Phase”?

November 20, 2021

Why is it called single-phase 240 when there are two opposing phases (or legs)?

I wondered why we called two 120v opposing legs “single-phase 240” for years.

Then someone pointed out to me that a typical “single-phase” pole transformer only has one power leg entering and two coming out.

That freaked me out. How can a transformer primary be one phase, a SINGLE sine wave, and put out two perfectly opposing sine 120v legs?

It's just two separate winding wraps in OPPOSITE directions on the secondary or more simply, the neutral is tapped in the center so OBVIOUSLY they wrap in opposite directions from the center out. Stupid simple, but I just never knew it.

So, unlike a three-phase service that uses all three power phases from the power supply, the single-phase service only uses one. The second leg is “created” in the secondary of the distribution transformer itself and is the same “phase” but is split due to the center tap.

Pretty cool.

—Bryan

Check out our most recent video

How to Evacuate an AC system, Full Vacuum Procedure

Our latest Podcast

HVAC School – For Techs, By Techs

Real training for HVAC ( Heating, Ventilation, Air Conditioning and Refrigeration) Technicians. Including recorded tech training, interviews, diagnostics and general conversations about the trade.

In this podcast, Bryan Orr and Bert discuss various aspects of pool heaters, focusing on issues that make them different from typical HVAC systems. They cover the basics of pool heaters – the main types (heat pumps and gas heaters) and how they operate similarly or differently from things HVAC techs work on regularly.

The bulk of the 45-minute podcast looks at common service and troubleshooting situations with pool heaters, which are usually installed by pool contractors initially and not HVAC contractors. Bryan and Bert talk through typical causes of common error codes and problems like units frequently going out on high pressure. They cover water flow issues and the role of pressure versus flow switches, the sizing and limitations of heat pumps, low ambient operation challenges, freeze protection, and proper refrigerant charging. There is also a good amount of discussion on gas pool heaters – frequent component failures due to heat and corrosion issues, piping considerations due to their large BTU capacity, and combustion troubleshooting basics.

Throughout the casual discussion, both hosts interject humor and personal stories related to their dealings with pool heater equipment, clients, and installations over the years. The overall message is that while heat pumps and gas pool heaters have some specialized considerations, much of the core knowledge needed to service them comes from foundational HVAC systems understanding combined with an awareness of the unique aspects covered in detail during this episode.

Topics Covered:

Types of pool heaters
How heat pump and gas pool heater operation compare to HVAC
Typical installation and service providers
Key components and design aspects
Common high-pressure issues and troubleshooting water flow problems
Low ambient operation challenges
Refrigerant charging considerations
Gas piping sizing for large BTU appliances
Corrosion issues and component failures
Combustion testing basics

Learn more about the 5th Annual HVACR Training Symposium at https://hvacrschool.com/Symposium24.

If you have an iPhone, subscribe to the podcast HERE, and if you have an Android phone, subscribe HERE.”

Subscribe to our YouTube channel at https://www.youtube.com/@HVACS.

Check out our handy calculators HERE or on the HVAC School Mobile App (Google Play Store or App Store).

Search Episodes

What's Different About Pool Heaters w/ Bert

11/30/2023

Bryan Orr

Farads, Micro and Pico – Short #180

11/28/2023

Bryan Orr

All About 90% Furnaces

11/23/2023

Bryan Orr

Analog vs. Digital Sine – Short #179

11/21/2023

Bryan Orr

Why and How of Combustion Analysis w/ Tyler Nelson

11/09/2023

Bryan Orr

Checking a Heat Pump in Heat Mode – Short #178

11/07/2023

Bryan Orr

An IAQ & Dehum Case Study w/ Genry & Nikki

11/02/2023

Bryan Orr

Creating a Business Where Everyone Wins w/ Tommy Mello

10/26/2023

Bryan Orr

Tips for Supermarket Rack Service w/ Trevor

10/19/2023

Bryan Orr

Traps, Vents & Drains – Short #177

10/17/2023

Bryan Orr

Search Results placeholder

Comments

Gary L Reecher

2/5/17 at 02:52 AM

It’s single phase because the two voltages are 180 degrees out of phase with each other. At one time there was two phase voltage where the two voltages were 90 degrees out of phase with each other.

Mark Kw

2/5/17 at 11:05 AM

“Phasing” requires having two sine waves occurring at some point other than 180° opposite each other. Single phase is such because the opposing sine waves are exactly 180° opposite each other, whereas “two phase” systems operate with the sine waves occurring at 90° apart and “three phase operates with the sine waves 120° apart. Phased systems allow motors to be self-starting, but single-phase motors require a start winding to create the electrical separation of 30° to facilitate starting rotation.

Mark Kw

2/5/17 at 11:17 AM

I should have added that the starting phase shift on a capacitor-start single phase motor is 90°

Bruce

11/21/21 at 03:53 PM

I never understood this. What does 180 degrees mean? Is it the distance of the magnetic poles?Also what’s the deal with the neutral attached to the winding with no electrical pressure?

Tom

1/12/22 at 12:29 PM

You’ll need to dig out your high-school trigonometry textbook and study the material about the unit circle and sine waves. “Oscar has a hairy old ass.”
