Through detailed 3D animations, Bryan will walk you through:

• The Suction Line – Carrying low-pressure cool refrigerant vapor away from the evaporator coil towards the compressor.
• The Discharge Line – Transporting hot, high-pressure superheated refrigerant vapor from the compressor to the condenser.
• The Liquid Line – Responsible for moving high-pressure subcooled liquid refrigerant from the condenser to the metering device.
• The Expansion Line – Existing in some systems to carry the saturated refrigerant mixture between the metering device and evaporator.

Bryan’s clear explanations, coupled with vivid 3D visuals, will help you visualize the pressure and temperature differences between these lines. You’ll understand critical concepts like superheat and subcooling and their importance for optimal system performance.
