Flow Hood: How to Properly Balance an HVAC System

August 14, 2024

HVAC expert Bert demonstrates how to use a flow hood to properly balance an HVAC system. Watch as he measures and adjusts airflow throughout the house, focusing on the newly installed ductwork and manual dampers.

Key points covered:

Measuring CFM (cubic feet per minute) at each vent
Adjusting manual dampers to balance airflow
Tips for handling oversized systems
Balancing techniques for different room types

This video provides valuable insights for HVAC professionals and homeowners alike, showcasing the importance of proper system balancing for optimal comfort and efficiency.

#airflow #balancing #dampers #ductwork #flow hood #hvac
