#voltage drop

Tech Tips:

What Causes Voltage Drop and How to Deal With It

Voltage drop is one of those topics we often mention but seldom think about in-depth. From a very basic standpoint, we need to know whether or not the rated voltage is being delivered to the device or appliance while under full load, which is as simple as running the equipment and measuring the voltage at […]

Measuring Voltage Drop w/ Jim Bergmann

In this episode, Bryan and Jim discuss measuring voltage drop and what it means. They also cover some other pointers to keep from using parts to bandage a deeper issue. A common mistake that technicians make is not understanding what an ideal measurement is before making a measurement. For example, they may not know what […]

Ruby Carlos

Check out our most recent video

How to Evacuate an AC system, Full Vacuum Procedure

Our latest Podcast

HVAC School – For Techs, By Techs

Real training for HVAC ( Heating, Ventilation, Air Conditioning and Refrigeration) Technicians. Including recorded tech training, interviews, diagnostics and general conversations about the trade.

In this enlightening episode, we sit down with Mike, a 20-year veteran from DITEK, a leading American manufacturer of surge protection devices based in Largo, Florida. The conversation begins with a brief discussion about recent hurricane impacts in the Tampa Bay area, where DITEK maintains its 65,000-square-foot manufacturing facility. Mike shares how the company, despite facing challenging weather conditions, continued its operations and maintained its commitment to American manufacturing.

The bulk of the discussion centers around surge protection technology and its critical importance in protecting HVAC systems and other electronic equipment. Mike provides an excellent analogy, comparing surge protectors to pressure relief valves for electrical systems. He explains how Metal Oxide Varistors (MOVs) work as semiconductors that create low impedance paths to ground when voltage exceeds certain thresholds. The conversation delves into the evolution of MOV technology, particularly the development of thermally protected MOVs that provide enhanced safety features.

The episode also addresses common misconceptions about surge protection, particularly the belief that surge protectors are primarily for lightning protection. Mike explains that while lightning strikes are a concern, especially in areas like Florida, approximately 65% of surges actually originate from within facilities themselves, often from equipment cycling on and off or other power quality issues. He emphasizes the importance of proper installation, particularly regarding ground connections and lead lengths, noting that every six inches of wire length can add about 100 volts to the clamping voltage of the device.

Key Topics Covered:

DITEK’s history and commitment to American manufacturing
Basic principles of surge protection and how MOVs work
Evolution of MOV technology and thermal protection features
Difference between transient voltage and temporary overvoltage (TOV)
Importance of proper grounding and lead length in surge protection
Cascading surge protection strategy for comprehensive protection
UL testing standards and voltage protection ratings (VPR)
Common misconceptions about surge protection
Impact of aging electrical infrastructure on power quality
Importance of customer support and ethical business practices
Installation best practices for surge protection devices
Relationship between ground resistance and surge protector performance
Types of surge protective devices (SPD) and their classifications

Learn more about DITEK at https://www.diteksurgeprotection.com/.
