#switches

Tech Tips:

On an energized, intact circuit, you will read voltage across an OPEN switch when testing with a voltmeter. However, you probably won't read significant voltage across a CLOSED switch. Both sides of a closed switch are electrically identical (or at least very close). Therefore, there should be no movement of electrons between the leads of […]

Open and Closed Case

I know I'm gonna get some eye-rolling here, but it needs to be said. When we teach electricity to new techs, we use a lot of “water” metaphors. We talk about volts like PSI, amps like flow, and watts like GPM (speaking of GPM in HVAC, check out our article on hydronics HERE). Even the […]
