Tech Tips:

Courtesy of Copeland The design goal of most modern compressors is to make them more efficient and better able to match loads, hopefully without reducing ruggedness. The Copeland Scroll Digital™ or digital scroll is one compressor design that has become very popular due to its simplicity and versatility. But before we go further, let's define […]

Scroll Compressor Pump Down, Megohm Test & Fusite Terminals

This tip will be like an episode of Columbo; we will start with the what and who and then get to the why. Don't pump down a scroll into a vacuum. Don't run a scroll in a vacuum. Don't run a high voltage megohmmeter or Hi-pot test on a scroll (As a general rule, don't […]

Scroll Compressors & Things to Check for Overheating

NOTE: If you cannot view the recording, the video may still be processing. The maximum wait time is 24 hours. We apologize for the delay and appreciate your patience.

dkpcelinda
#compressor #fusite #pump down #scroll #vacuum

Check out our most recent video

How to Evacuate an AC system, Full Vacuum Procedure

Our latest Podcast

HVAC School – For Techs, By Techs

Real training for HVAC ( Heating, Ventilation, Air Conditioning and Refrigeration) Technicians. Including recorded tech training, interviews, diagnostics and general conversations about the trade.

In this episode of the HVAC School Podcast, host Bryan welcomes Jeff from Copeland to discuss the critical topic of flooding and slugging in compressors. Jeff, calling in from frigid Minnesota (at negative 19°F), explains the differences between these harmful conditions and how they can damage compressor systems.

The conversation begins by differentiating between flood back and flooded starts. Flood back occurs during system operation when control of the evaporator is lost, often due to airflow issues. Flooded starts happen after the system has been off, when refrigerant migrates to the compressor oil. Both conditions can lead to slugging – when liquid refrigerant enters the compression chamber, causing immediate damage to valves and internal components. While flood back and flooded starts may cause gradual damage over time, slugging can break compressor components instantly.

Jeff emphasizes that proper superheat levels are essential for compressor health, with most Copeland compressors requiring about 20 degrees of superheat at the compressor suction line. The discussion covers various preventative measures, including pump down systems, properly installed crankcase heaters, and the importance of maintaining appropriate refrigerant charge. Jeff notes that many technicians incorrectly assume crankcase heaters are only needed in cold climates, when they’re actually crucial for preventing refrigerant migration in any environment.

Key Topics Covered:

The difference between flood back (during operation) and flooded starts (when the system restarts)
How slugging causes immediate damage to compressors while flooding causes progressive damage
The importance of maintaining proper superheat (typically 20 degrees at the compressor)
Common causes of flood back: dirty filters, improper airflow, duct problems, and incomplete defrosting
How refrigerant is attracted to compressor oil even in vapor form
Prevention strategies: pump down systems, proper crankcase heater installation and verification
The impact of line sizing and total refrigerant charge on system reliability
Why compressors are designed for vapor-in/vapor-out operation, not liquid handling
The importance of consulting OEM literature and Copeland resources when troubleshooting
Why it’s critical to identify and fix the underlying cause before replacing a failed compressor
