#Rooftop

Tech Tips:

Crane Considerations for RTU Installation

Sandhill cranes are protected by the Migratory Bird Treaty Act (MBTA) of 1918. Non-migratory subspecies, like the ones we see in Florida, also have special protections, and hurting a crane can land you in jail or put you thousands of dollars in debt. (Plus, it’s just plain awful.) For that reason, we need to do […]

5 Things to Consider When Maintaining a Commercial Package Unit

If you are primarily a residential technician working on equipment under 5 tons, there are many similarities between the systems you are used to and 5-20 ton rooftop units common to the light commercial market. There are MANY additional things to consider on larger equipment, and here are just a few. Wash Fresh Air Filters […]

IaVsrDxldXkHhBuq
#commercial hvac #Rooftop #RTU

Check out our most recent video

How to Evacuate an AC system, Full Vacuum Procedure

Our latest Podcast

HVAC School – For Techs, By Techs

Real training for HVAC ( Heating, Ventilation, Air Conditioning and Refrigeration) Technicians. Including recorded tech training, interviews, diagnostics and general conversations about the trade.

In this short Q&A podcast episode, Bryan answers a listener-submitted question about superheat, including what it is and how we measure it.

Superheat is the number of degrees a refrigerant is above its saturation point. The saturation point is where you will have a liquid-vapor mix, so superheat only exists when a substance is a vapor. Saturated refrigerant should only exist in the evaporator and condenser, during which it is being boiled or condensed.

We usually measure superheat at the evaporator coil outlet and compressor inlet. The superheat at the evaporator outlet is usually around 5-14 degrees Fahrenheit, and it’s often between 10 and 20 degrees at the compressor inlet (compressor superheat). However, many systems try to get lower superheat values, and some manufacturers may require higher superheat values at the compressor inlet to prevent liquid refrigerant from getting into the compressor. Accumulators can help keep liquid refrigerant out of the system as well. We may also measure superheat coming out of the compressor on the discharge line (discharge superheat); this superheat may exceed 100 degrees Fahrenheit. Discharge superheat can let you know if the compressor is overheating the oil and causing breakdown or carbonization.

We use superheat to set the charge for fixed-orifice metering devices (as opposed to subcooling for TXVs), as superheat is a measure of how well we’re feeding our evaporator coil. When the system is off, the superheat will be 0. A system will equalize, and the refrigerant will be at saturation when that happens.
