Tech Tips:

I'd like to give a special thanks to Tony Gonzalez from Fieldpiece for providing technical guidance about the SC680's power measurement capabilities, as well as VAC and AAC measurements on ECMs. We’ve talked through specifications, applications, and features for a few tools, but none of them have been quite as hardcore as electrical meters. Like […]

Switch Voltage

On an energized, intact circuit, you will read voltage across an OPEN switch when testing with a voltmeter. However, you probably won't read significant voltage across a CLOSED switch. Both sides of a closed switch are electrically identical (or at least very close). Therefore, there should be no movement of electrons between the leads of […]

What Is Up With Blower Amps & Watts w/ Steve Rogers

Bryan Orr and Steve Rogers dive deep into measuring power consumption in HVAC blower motors, particularly focusing on the differences between PSC (Permanent Split Capacitor) and ECM (Electronically Commutated Motor) technologies. The discussion stems from a question raised at an educators' conference about the accuracy of clamp-on meters in measuring blower motor watt draw, […]

bennydenham58
#current #switches #volt #voltage #voltmeter

Check out our most recent video

How to Evacuate an AC system, Full Vacuum Procedure

Our latest Podcast

HVAC School – For Techs, By Techs

Real training for HVAC ( Heating, Ventilation, Air Conditioning and Refrigeration) Technicians. Including recorded tech training, interviews, diagnostics and general conversations about the trade.

In this short podcast, Bryan talks about evaporator coil placement based on a question submitted by a listener, John. Evap coil placement differs in furnace applications versus air handlers.

When we use air conditioners with furnaces, we usually put evaporator coils on the positive side to protect the heat exchanger from rusting out during the summer (due to condensation and the chemical reactions that can occur with the metal heat exchanger). However, when it comes to air handlers, they’re usually on the negative side. The coil is usually on the negative side of a fan coil or air handler because it keeps the blower motor cooler (though that doesn’t make a huge difference in terms of performance).

The HVAC system will lose fewer BTUs to leakage when the coil is on the negative side, which is better for energy efficiency; those BTUs can reach the conditioned space rather than the closet, garage, or wherever it is stored. Pulling air over the evaporator coil on the negative side, however, could potentially lead to greater turbulence.

We run into challenges with evap coil placement on gas furnaces when we have dual fuel systems (a heat pump and furnace working together). You can’t run gas heat over a heat pump coil due to the high head pressure, so a parallel setup would avoid the risks of high head pressure (downstream) or rusted-out heat exchangers (upstream).
