Tech Tips:

First, let's get something straight: BRAZING is when you use a filler rod that isn't the same material as the base metal but melts ABOVE 840°F. Soldering is the same but at temperatures BELOW 840°F. With HVAC rods melting at around 1200°F, it confuses me why we usually call it “silver solder” but also often call it […]

Oleksandr Kiiashko
##capacitors ##hvacnerds ##meters #15% #208v #hvac

Check out our most recent video

How to Evacuate an AC system, Full Vacuum Procedure

Our latest Podcast

HVAC School – For Techs, By Techs

Real training for HVAC ( Heating, Ventilation, Air Conditioning and Refrigeration) Technicians. Including recorded tech training, interviews, diagnostics and general conversations about the trade.

In this short podcast, Bryan talks about evaporator coil placement based on a question submitted by a listener, John. Evap coil placement differs in furnace applications versus air handlers.

When we use air conditioners with furnaces, we usually put evaporator coils on the positive side to protect the heat exchanger from rusting out during the summer (due to condensation and the chemical reactions that can occur with the metal heat exchanger). However, when it comes to air handlers, they’re usually on the negative side. The coil is usually on the negative side of a fan coil or air handler because it keeps the blower motor cooler (though that doesn’t make a huge difference in terms of performance).

The HVAC system will lose fewer BTUs to leakage when the coil is on the negative side, which is better for energy efficiency; those BTUs can reach the conditioned space rather than the closet, garage, or wherever it is stored. Pulling air over the evaporator coil on the negative side, however, could potentially lead to greater turbulence.

We run into challenges with evap coil placement on gas furnaces when we have dual fuel systems (a heat pump and furnace working together). You can’t run gas heat over a heat pump coil due to the high head pressure, so a parallel setup would avoid the risks of high head pressure (downstream) or rusted-out heat exchangers (upstream).
