Common Callbacks and Failed Inspections on Install

In this episode of HVAC School, hosts Bryan Orr and Bert discuss practical tips for preventing callbacks and failed inspections in residential HVAC installs and maintenance.

Bryan and Bert stress the importance of getting the basics right, like properly cleaning condensate drains, ensuring proper drain pitch, and sealing ducts completely before relying on tapes and mastic to cover gaps. They emphasize verifying full system operation at the end of a job, from checking that drains flow freely to testing float switches and pressure testing for leaks. Bryan and Bert also cover wire and breaker sizing for equipment changes, securing disconnects, proper thermostat wall seals, inspecting joints with bubbles to find microscopic leaks, and more thorough evacuations and leak checks.

Throughout the casual, conversational show, the hosts inject colorful commentary on doing quality work with a little sarcasm, including praising the merits of duct board and flex ducts. The tone is partly tongue-in-cheek but drives home the point that shortcuts lead to callbacks and leave clients dissatisfied.

Bert and Bryan also discuss:

Becoming masters of the obvious
Common condensate line issues
The issues with double traps
Ensuring adequate filter access for the customer
Wiring float switches in series vs. in parallel
Sealing ductwork effectively
Using your senses to find airflow leaks in the ductwork
Pressure testing for refrigerant leaks
Common leak points in systems and their causes
Correct electrical setup and markings
Securing outdoor unit placement
Sealing thermostat wall penetrations
Thorough evacuation and leak checks

Learn more about the 5th Annual HVACR Training Symposium at https://hvacrschool.com/Symposium24.

If you have an iPhone, subscribe to the podcast HERE, and if you have an Android phone, subscribe HERE.”

Subscribe to our YouTube channel at https://www.youtube.com/@HVACS.

Check out our handy calculators HERE or on the HVAC School Mobile App (Google Play Store or App Store).

Comments

Pumping vs. Compression – Short #218

Building Tech Confidence w/ Refrigeration Mentor

Molecular Transformator – Short #217

Surge Protection Basics w/ DITEK

Q&A – Am I Toxic For Caring? – Short #216

App Based HVAC Learning

Q&A – Apps for Doing Proper Loads – Short #215

Jim Bergmann & MQ Update from NCI Summit

Q&A – System Won’t Dehumidify? – Short #214

What Is Up With Blower Amps & Watts w/ Steve Rogers

#callbacks #condensate drain #hvac #inspections

Author:

Bryan Orr

Company: HVAC School

Position: Founder

Bert Testerman

Check out our most recent video

How to Evacuate an AC system, Full Vacuum Procedure

Our latest Podcast

HVAC School – For Techs, By Techs

Real training for HVAC ( Heating, Ventilation, Air Conditioning and Refrigeration) Technicians. Including recorded tech training, interviews, diagnostics and general conversations about the trade.

In this short episode, Bryan clears up the confusion behind pumping vs. compression.

Pumping is usually associated with liquid. Liquid, like vapor, is a fluid, but it’s a lot denser and is essentially incompressible because the molecules are close together. Liquid volume varies based on temperature and density, but we can’t squish the molecules together. That’s why compressors with very little axial and radial compliance fail when flooded; they can’t compress the liquid. A circulator pump in a hydronic system is an example of a pump that pushes liquid along, but the pressure difference across the pump is minimal compared to that of a compressor; the same is true of liquid vs. vapor CO2.

However, vapor molecules are far apart and can be squished together to take up a smaller volume. That’s why vapor can go through compressors, which take a fluid of one volume and apply pressure to shrink it to a smaller volume, raising the temperature in the process. Pneumatics, as opposed to hydraulics, utilize compression to move vapor around in a circuit. Recovery machines need to be able to compress vapor refrigerant and pump liquid into the recovery tank.

Compressors and pumps can either be positive displacement or non-positive displacement systems. A positive displacement system creates a trap and forces a fixed amount of fluid through a system, like a scroll compressor or a circulator pump. Refrigerant volumes may vary because vapor density varies with temperature and pressure (the volume flow is the same, but the mass flow varies). A condensing fan motor, on the other hand, is dynamic and varies the volume of air it moves in response to pressure, as the mechanism relies on velocity and kinetic energy to move air.
