Alex Meaney – HVAC Design Backwards, Forwards, and In Between

This podcast episode is one of Alex Meaney's HVACR Training Symposium presentations: HVAC Design Backwards, Forwards, and In Between.

Load calculation factors in all three means of heat transfer: conduction, convection, and radiation. It doesn't directly tell you the tonnage; it just tells you how many BTUs (sensible and latent) are entering or leaving a structure. When designing systems after doing load calculations, we need to be mindful of industry standards and their pitfalls, as well as the climate conditions and the difficulty of obtaining manufacturer data.

Equipment selection by tonnage is only part of the picture when it comes to HVAC design; we also need to factor in airflow and duct design, especially duct sizing. However, many rules of thumb and poorly explained terms are counterproductive to a thorough understanding of HVAC design. In some cases, the best way to design a system may seem “backward,” especially when starting with blower selection instead of ductwork.

Duct design is particularly difficult, especially when software identifies several problems with designs that seemed to look good on paper. However, the software points out areas where you can adjust the duct size and manage restrictions to allow the fan to do its job without being derated by friction.

Alex also covers:

Insulation and efficiency ratings
CLTD Groups
Tricky radiant gains and losses
The relationship between BTUs and tons
AHRI ratings
Shortcomings of Ductulators in duct design education
Pressure vs. friction in ductwork
Static pressure vs. velocity pressure
Measuring friction with pressure
Regulations vs. reality
Furnace static pressure range
Differences between commercial and residential duct design
Oversized and under-ducted systems
Variable-capacity systems
ACCA manuals and tables

Check out Alex Meaney's consultation business at https://www.meanhvac.com/.

Learn more about the HVACR Training Symposium or buy a virtual ticket today at https://hvacrschool.com/symposium.

If you have an iPhone, subscribe to the podcast HERE, and if you have an Android phone, subscribe HERE.

Check out our handy calculators HERE.
